48″ Philips Q-Line Display – BDL4830QL
48″ Phiips Q-Line Display – BDL4830QL
360 Nit Full HD Backlit LED/LCD with HTML5 Browser, USB Scheduling, 16/7 operation
Deliver startlingly clear images in a more eco-friendly way.
High on performance and reliability, yet low on power consumption, it is ideal for projects where no compromise is accepted.
Description
Picture/Display
•Diagonal screen size: 47.6 inch / 120.9 cm
•Panel resolution: 1920x1080p
•Optimum resolution: 1920 x 1080 @ 60 Hz
•Brightness: 350 cd/m²
•Contrast ratio (typical): 4000:1
•Dynamic contrast ratio: 500,000:1
•Response time (typical): 8 ms
•Aspect ratio: 16:9
•Viewing angle (H / V): 178 / 178 degree
•Pixel pitch: 0.549 x 0.549 mm
•Display colors: 16.7 Million
•DICOM: Clinical D-image
Supported Display Resolution
•Computer formats
Connectivity
•Video input: DVI-D, HDMI, Component (RCA), Composite (RCA), VGA (Analog D-Sub)
•Audio input: 3.5 mm jack, Audio Left/Right (RCA)
•Audio output: Audio Left/Right (RCA), 3.5mm jack
•External control: RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack
•Other connections: USB
Dimensions
•Bezel width: 11.9 (TLR) / 14.7 (B) mm
•Set dimensions (W x H x D): 1081.8 x 623.4 x 59.9 mm
•Set dimensions in inch (W x H x D): 42.59 x 24.54 x 2.36 inch
•VESA Mount: 400 x 400 mm, 200×200 mm, M6
•Product weight: 11.52 kg
•Product weight (lb): 25.4
Operating conditions
•Temperature range (operation): 5 ~ 40 °C
•Temperature range (storage): -20 ~ 60 °C
•Relative humidity: 20 ~ 80 %
•MTBF: 50,000 hour(s)
Sound
•Built-in speakers: 2 x 10W RMS
Multimedia Applications
•USB Playback Video: 3G2, 3GP, ASF, ASX, AVI, DAT, DivX, F4V, FLV, M2TS, M4V, MK3D, MKV, MOV, MP4, MPE, MPEG, MPG, MTS, QT, TRP, TS, TTS, VOB, WEBM, WMV, Xvid
•USB Playback Picture: BMP, GIF, JPEG, JPG
•USB Playback Audio: AAC, AC3, AIF, AIFF, AMR, EC3, M4A, MP3, OGA, OGG, WAV, WMA
•Warranty: Global: 3 years
Specifications
| Picture/Display | |
| Diagonal screen size (metric) | 120.9 cm |
| Diagonal screen size (inch) | 47.6 inch |
| Panel resolution | 1920x1080p |
| Optimum resolution | 1920 x 1080 @ 60 Hz |
| Brightness | 350 cd/m² |
| Contrast ratio (typical) | 4000:1 |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 ms |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 degree |
| Viewing angle (vertical) | 178 degree |
| Pixel pitch | 0.549 x 0.549 mm |
| Display colors | 16.7 Million |
| DICOM | Clinical D-image |
| Convenience | |
| Memory | Internal memory access |
| 8GB eMMC | |
| Screen saving functions | Pixel Shift |
| Energy saving functions | Smart Power |
| Tiled Matrix | Up to 15 x 15 |
| Start-up | Wake up on LAN |
| Switch on delay | |
| Switch on status | |
| Start-up window | enable / disable Philips logo |
| Keyboard control | Lockable |
| Hidden | |
| Network controllable | RS232 |
| RJ45 | |
| One Wire (HDMI-CEC) | |
| Signal Loop Through | RS232 |
| IR Loopthrough | |
| Operating conditions | |
| Temperature range (operation) | 5 ~ 40 °C |
| Temperature range (storage) | -20 ~ 60 °C |
| Relative humidity | 20 ~ 80 % |
| MTBF | 50,000 hours |
| Power | |
| Consumption (On mode) | 115 W (EnergyStar 6.0 test method) |
| Mains power | 100 ~ 240 VAC |
| Standby power consumption | <0.5 W |
| Accessories | |
| Included accessories | AC Power Cord |
| RS232 cable | |
| VGA cable | |
| Remote Control | |
| Batteries for remote control | |
| User manual on CD-ROM | |
| Quick start guide | |
| Miscellaneous | |
| Warranty | 3 year warranty |
| On-Screen Display Languages | English |
| French | |
| German | |
| Italian | |
| Polish | |
| Turkish | |
| Russian | |
| Simplified Chinese | |
| Spanish | |
| Traditional Chinese | |
| Regulatory approvals | CE |
| CCC | |
| UL/cUL | |
| C-Tick | |
| BSMI | |
| CB | |
| GOST | |
| CECP | |
| EPA | |
| Supported Display Resolution | |
| Computer formats | 640 x 480, 60, 67, 72, 75Hz |
| 800 x 600, 56, 60, 72, 75Hz | |
| 1024 x 768, 60Hz | |
| 1280 x 768, 60Hz | |
| 1280 x 800, 60Hz | |
| 1360 x 768, 60Hz | |
| 1366 x 768, 60Hz | |
| 1440 x 900, 60Hz | |
| 1920 x 1080, 60Hz | |
| 1920 x 1200, 60Hz | |
| Video formats | 480i, 60Hz |
| 480p, 60Hz | |
| 576p, 60Hz | |
| 576i, 50Hz | |
| 720p, 50Hz, 60Hz | |
| 1080i, 50, 60Hz | |
| 1080p, 50, 60Hz | |
| Connectivity | |
| Video input | DVI-D |
| HDMI | |
| Component (RCA) | |
| Composite (RCA) | |
| VGA (Analog D-Sub) | |
| Audio input | 3.5 mm jack |
| Audio Left/Right (RCA) | |
| Audio output | Audio Left/Right (RCA) |
| 3.5mm jack | |
| External control | RJ45 |
| RS232C (in/out) 2.5 mm jack | |
| IR (in/out) 3.5 mm jack | |
| Other connections | USB |
| Dimensions | |
| Bezel width | 11.9 (TLR) / 14.7 (B) mm |
| Set Width | 1081.8 mm |
| Set Height | 623.4 mm |
| Set Depth | 59.9 mm |
| Set Width (inch) | 42.59 inch |
| Set Height (inch) | 24.54 inch |
| Set Depth (inch) | 2.36 inch |
| VESA Mount | 400x400mm, 200×200 mm, M6 |
| Product weight | 11.52 kg |
| Product weight (lb) | 25.4 lbs |
| Sound | |
| Built-in speakers | 2 x 10W RMS |
| Multimedia Applications | |
| USB Playback Video | 3G2 |
| 3GP | |
| ASF | |
| ASX | |
| AVI | |
| DAT | |
| DivX | |
| F4V | |
| FLV | |
| M2TS | |
| M4V | |
| MK3D | |
| MKV | |
| MOV | |
| MP4 | |
| MPE | |
| MPEG | |
| MPG | |
| MTS | |
| QT | |
| TRP | |
| TS | |
| TTS | |
| VOB | |
| WEBM | |
| WMV | |
| Xvid | |
| USB Playback Picture | BMP |
| GIF | |
| JPEG | |
| JPG | |
| USB Playback Audio | AAC |
| AC3 | |
| AIF | |
| AIFF | |
| AMR | |
| EC3 | |
| M4A | |
| MP3 | |
| OGA | |
| OGG | |
| WAV |
