Rayon B70POE – Network powered single

Rayon B70POE – Network powered single channel sound bar
Max SPL: 94dB at 5m
Advantage of B70TC: Optimised horizontal coverage
Bandwidth: 120Hz-18kHz
Continuous power: 60W
5 years warranty

SKU: Rayon-B70-POE Brand:


Ray-On PoE serie allows to the patented DGRC (Digital and Geometric Radiation Control) technology to be easily integrated in smart buildings. This innovation yield homogenous sound coverage and perfect intelligibility. The elegant design of Ray-On loudspeakers with their finely perforated grid, the ability to dispose of all colors thanks to a paintable cast aluminium body, and the vertical installation of the columns inherent to the DGRC technology allow achieving optimal results in terms of aesthetics and integration.

Based on the expertise of Active Audio in the field of directivity control by loudspeakers arrays, the Ray-On B70PoE sound bar focuses on the directivity control of loudspeaker alignments on the horizontal plane.
The directivity of the B70 provides excellent intelligibility, even in reverberant and longilineal spaces or to limit the noise pollution on the adjacent areas in shopping malls or museums.
The elegant design and the finesse of the B70PoE enclosure combined with its horizontal laying mode allow to obtain an easy and aesthetic integration.
The integrated 60W PoE+ amplifier module allows to power and put audio signal in the column with a single CAT6 cable. Ray-OnB70 PoE can be installed close to any RJ45 socket connected to a network switch with a PoE+ port.

Equipped with an AES67 compatible DANTE input on RJ45 connector, Ray-OnB70PoE is designed to be integrated into complex digital networks. The internal DSP of the enclosure provides an optimal frequency response. With a similar design Ray-On R70PoE exists in 75W low impedance or 70V/100V version under the reference Ray-On B70 TC.
