Rayon R110PoE – Network powered single channelcolumn loudspeaker

Ray-On PoE serie allows to the patented DGRC (Digital and Geometric Radiation Control) technology to be easily integrated in smart buildings. This innovation yield homogenous sound coverage and perfect
intelligibility. The elegant design of Ray-On loudspeakers with their finely perforated grid, the ability to dispose of all colors thanks to a paintable cast aluminium body, and the vertical installation of the columns inherent
to the DGRC technology allow achieving optimal results in terms of aesthetics and integration.
The integrated 60W PoE+ amplifier module allows to power and put audio signal in the column with a single CAT6 cable. Ray-On PoE can be installed close to any RJ45 socket connected to a network switch with a
PoE+ port.
Equipped with an AES67 compatible DANTE input on RJ45 connector, Ray-On PoE is designed to be integrated into complex digital networks.
The internal DSP of the enclosure provides a DANTE input and an optimal frequency response.
The Ray-On PoE column loudspeakers can be used indoors only, enabling them to meet the needs of sound systems meeting rooms,
conference rooms, or shopping malls.
With a height of 110cm, the Ray-on R110PoE column has a nominal range of 20m for a continuous power of 60W. Its characteristics
are perfect for medium-range venues or in distributed sound reinforcement system. Its nominal installation height of 2,2m allows a safety set up in public places. With a similar height Ray-On R110PoE
exists in 150W self amplified version under the reference Ray-On 110+ and in low impedance or 70V/100V version under the reference Ray-on R110.
